Controls one door directly, with unlimited expansion capabilities
Connect and power using an existing Ethernet network infrastructure
- TCP/IP communications (100/10Mbps)
- DHCP or Static IP addresses

Password protected built-in webserver or FREE downloadable ‘Grid’ software
Two Ethernet Ports allow for interfacing with additional IP devices like cameras additional door controllers, etc.
Live transaction monitoring
Entry & exit reader capability
Supports industry standard proximity, smart card, and multi-technology readers (Wiegand output)
Reader short circuit protection
Compliant with PoE+ standard
Up to 60,000 users (up to 2 credentials per user)
Batch card enrollment
250 Time Zones and 1,000 User/Door Groups
Holiday support
Scheduled Events
Temporary Users
Audit Trail – Up to 5,000 events from on-board storage, unlimited events with PLUS software (limited only by your allocated server space)
Status LED’s – Power, Communications, & Fault on-board diagnostic indicators
Anti-tailgating
Anti-passback (global or localized)
Supported browsers: Microsoft Internet Explorer, Firefox, Google Chrome
Multiple credential modes: Card only, PIN only, Pin or Card, Pin & Card
Door Status Monitoring Input
Request-to-Exit (REX) Input
Programmable Auxiliary Input
Lock Relay Output
Auxiliary Relay Output
(2) Programmable Solid-state Outputs
Tamper Input
Database backup support
Current consumption 450mA

SDC IP Pro
